Q: A cantilever 2 m long beam carries point loads of 300, 500 and 800 N respectively at 0.5, 1.2 & 2 m from the fixed end. What will be the shear force (in N units) at the fixed end and bending moment (in N.m units) at the free end? 2 मीटर लम्बी एक प्रास धरन 300, 500 तथा 800 N भार से क्रमश: 0.5, 1.2 तथा 2 मीटर पर वहन करती है। आबद्ध सिरे पर कर्तन बल (N इकाई में) तथा मुक्त सिरे पर नमन आघूर्ण (N-m इकाई में) क्या होगा।
  • A. 800, 640
  • B. 500, 2350
  • C. 1600, 0
  • D. 800, 0
Correct Answer: Option C -
answer image

Explanations:

explanation image
